Assignment 1 - Software Rasterizer

Due Friday 4/14 at 11:55 pm. You must work individually.

Goal

Create a program that reads in and renders an indexed face set meshes (of type .obj) to an image via software rasterization. You may use existing resources to load in the mesh and to write out an image. You must write your own rasterizer. In general the required steps for the program are:

Task 1

Download the base code, which has a mesh loader and an image writer.

The mesh loader is an obj loader from http://github.com/syoyo/tinyobjloader, and the image writer is the same as the one used in prior labs.

Example mesh files are included in the base code, and you can create your own to represent a single triangle, etc. In addition, there are numerous OBJ meshes on the web. For grading purposes, your program will be run using the provided Stanford Bunny and Utah Teapot.

Ultimately you will want each triangle to be represented in a C/C++ structure/class, with 3 vertices and a color per vertex. In addition, your triangle data should include a 2D bounding box, which will represent the triangle's extents in window coordinates.

Task 2

Add a command line argument to accept the following command line arguments.

For example, your program should be able to be run as follows:

> ./Assignment1 bunny.obj output.png 512 512 1

Add error checking to specify the required command line arguments if an incorrect number are given – and include an example correct command line run. Your program should not dump core if no input file is specified, nor fail without an error message! Follow the golden rule, treat your user/grader/instructor the way you'd like to be treated as a user/grader/instructor.

Task 3

Write code to convert each 3D coordinate into 2D window coordinates. Assume the camera is at the origin looking down negative z. Make sure the object completely fills the image. Some tips for starting out:

Write out the bounding box, rather than the triangles, to the image. If you do this with the provided sphere, teapot, and bunny, you should see blocky images like below. Make sure the object takes up the whole image and is centered.

Once the bounding boxes are being displayed correctly, you can add the barycentric test to write out the triangles as in Lab02. You should not see any gap between the triangles.

Make sure you test nonuniform window sizes. As show below, the aspect ratio of the object should be preserved no matter what the image size is, and the object should fill out the image.

Here is another image of a bunny and a teapot, from Alice in Wonderland [Wikimedia] (credit to Sueda for the clever reference).

Task 4

Create a data structure to support z-buffer tests. Your z-buffer should be a separate buffer from your image pixel buffer, and it should be the same size as your pixel buffer.

Incorporate your lab code to rasterize a triangle with a color defined per vertex. Any point within the triangle should be drawn with colors interpolated via the barycentric coordinates. Likewise, depth should also be interpolated using the barycentric coordinates and written to the z-buffer.

Use the z value of the vertices as the color. (You can choose any color, not just red.) To do this, you have to map the z-value to the range 0 to 255. If your z-buffer test is not working, you'll see some strange results, since some pixels that are farther from the camera may be drawn on top of closer pixels.

Task 5

Use the "color mode" command line argument to switch between two modes. If mode is 1, then use the z-value as in the previous task. If mode is 2, then use the y-value to linearly interpolate two colors of your choice. For example, in the right figure below, I am interpolating between yellow and cyan. Make sure to specify these two colors in your README. The color should vary smoothly from top to bottom.

Important Note

Make sure to pass your std::vector by reference rather than by value. (E.g., void foo(std::vector<float> &bar)) Otherwise, your program may become too slow.

Point breakdown

Total: 100 points

What to hand in

Failing to follow these points may decrease your "general execution" score. Make sure that your code compiles and runs by typing, for example:

> mkdir build
> cd build
> cmake ..
> make
> ./Assignment1 <ARGUMENTS>
